Note: The above data represent the maximum values of the specification of the machine. Imperial dimensions are in brackets. The company reserves the right to make changes.
Specifications & Range
Model No.
SC-VBM-20
Unit
(Imperial)
Table Diameter
1600
mm
(5' 3")
Swing Diameter
2000
mm
(6' 7")
Max. Machining Height
1600
mm
(5' 3")
Ram Stroke
1400
mm
(4' 7")
Ram Cross Section
250 x 210
mm
(9.8" x 8.3")
Tool Feed Rate
0.1 - 2000
mm/min
(0.004" - 6' 7")
Table Turning Speed
2.5 - 250
rpm
Table Power
55
kW
(74 HP)
Table Torque
25
kNm
Tool Taper
# 50/60
ISO
Loading Capacity
11
ton
Specifications & Range
Model No.
SC-VBM-25
Unit
(Imperial)
Table Diameter
2000
mm
(6' 7")
Swing Diameter
2500
mm
(8' 2")
Max. Machining Height
2000
mm
(6' 7")
Ram Stroke
1400
mm
(4' 7")
Ram Cross Section
250 x 210
mm
(9.8" x 8.3")
Tool Feed Rate
0.1 - 2000
mm/min
(0.004" - 6' 7")
Table Turning Speed
2 - 200
rpm
Table Power
55
kW
(74 HP)
Table Torque
32
kNm
Tool Taper
# 50/60
ISO
Loading Capacity
16
ton
Specifications & Range
Model No.
SC-VBM-30
Unit
(Imperial)
Table Diameter
2500
mm
(8' 2")
Swing Diameter
3150
mm
(10' 4")
Max. Machining Height
2500
mm
(8' 2")
Ram Stroke
1400
mm
(4' 7")
Ram Cross Section
250 x 210
mm
(9.8" x 8.3")
Tool Feed Rate
0.1 - 2000
mm/min
(0.004" - 6' 7")
Table Turning Speed
1.6 - 160
rpm
Table Power
55
kW
(74 HP)
Table Torque
40
kNm
Tool Taper
# 50/60
ISO
Loading Capacity
25
ton
Note: These machines can be upgraded to have the life spindle inside the ram. The model numbers would add "M" as the end, such as "SC-VBM-25M" for the upgraded version of the same machine by adding the life spindle.
